Yamawa Manufacturing Co.
Manufacturer contact: 0120-800-418【Features】
●Designed exclusively for machines equipped with a fully synchronized lead screw feed mechanism.
●Adopts an appropriate groove shape for titanium alloys, ensuring smooth chip removal.
●Made with a suitable oversize considering the contraction of the threaded part.
●Uses high-grade powder high-speed steel with excellent heat resistance and wear resistance.
●Performs second thread cutting considering shrinkage and cutting heat.
●Surface treatment is applied to enhance wear resistance.
【Applications】
●For stop hole processing.
●Work material: titanium alloy.
【Specifications】
●Accuracy: P3
●Nominal size: M6
●Pitch (mm): 1
●Thread length (mm): 11
●Overall length (mm): 62
●Shank diameter (mm): 6
●Shank square part (mm): 4.5
●Pre-hole diameter (mm): 5.09
●Processed thread: metric thread
●Number of cutting edges: 3
●Surface treatment: nitriding process
【Specifications 2】
●Tap grade: P grade
【Material/Finish】
●Powder high-speed steel (HSS-P)
【Caution】
●Do not use this tap with machines that do not have a fully synchronized lead screw feed mechanism, as it may cause thread expansion or breakage.
【Country of origin】
Japan
| Product # | ED440674 |
|---|
