Code: 4969363047113

Brand: Shimano (SHIMANO)

Model: 047113

Product color: Black

Product weight: 215

About this product
Gear ratio: 6.2 / Practical drag force (kg): 6 / Maximum drag force (kg): 11 / Weight (g): 215
Spool diameter/stroke (mm): 52/19
Line capacity: Nylon (号-m) 3.5-170, 4-150, 5-125 / Fluoro (号-m) 3-190, 4-145, 5-115 / PE (号-m) 1-490, 1.5-320, 2-240
Maximum retrieve length (cm/handle rotation): 101 / Handle length (mm): 57
Number of bearings (BB/roller): 7/1
› See more brands Shimano (SHIMANO)
Hand orientation: Ambidextrous
Color: Black
Material: Carbon fiber
Fishing techniques: Shore, surf, saltwater
Product weight: 0.22 kilograms
Gear box ratio: 6.2
Model name: 24 Vanford
Maximum drag force of the fishing reel: 11 kilograms
Manufacturer: Shimano (SHIMANO)
About this product
Gear ratio: 6.2 / Practical drag force (kg): 6 / Maximum drag force (kg): 11 / Weight (g): 215
Spool diameter/stroke (mm): 52/19
Line capacity: Nylon (号-m) 3.5-170, 4-150, 5-125 / Fluoro (号-m) 3-190, 4-145, 5-115 / PE (号-m) 1-490, 1.5-320, 2-240
Maximum retrieve length (cm/handle rotation): 101 / Handle length (mm): 57
Number of bearings (BB/roller): 7/1
› See more

Shipping size: Height 17.5, Width 14.6, Depth 10.4

Shipping weight: 390

Brand introduction

Reel

Access store


Rod

Access store


Lure

Access store


Entry model

Access store


Line

Access store


Apparel

Access store


Shoes, waders

Manufacturer's description

As the core model of the Magnum Light series, which pursues agility and response in reeling, Vanford is active in a wide range of games including technical and finesse styles. It inherits the light operability, sensitivity, and comfortable winding feel of the previous model, while the inclusion of Infinity Cross and Infinity Drive greatly enhances powerful winding and gear durability. The adoption of Duracross, which has excellent wear resistance, has significantly improved drag durability—about 10 times compared to previous Shimano standards. Additionally, the anti-twist fin suppresses line trouble, further enhancing comfort. The 13 items cover area trout, bass fishing, eging, seabass, and shore jigging, making it a lineup suitable for the new era of lure games.

Concentrated mechanism, intense personality

A sporty form that hints at practical tools. The iconic red accent emphasizes three-dimensionality. The 24 Vanford aims for a balanced design that combines functionality and lightness. It has established a personality worthy of the Vanford name as a reliable partner throughout the day. Lightness, operability, and a sense of solid winding. The slim, sharp silhouette embodies unwavering trust cultivated through practical experience.

New possibilities brought by the lightweight rotor

In games that prioritize agility, controlling the start of lure movement, action contrast, or uniformity of reeling is key. The Magnum Light series introduces a lightweight Magnum Light rotor, focusing on this point. By thoroughly eliminating waste and reducing inertia, it improves the response of initial reeling and static state, sharpening the angler's sense and operability.

What low inertia means is that the reel can start rotating with light force and can be controlled precisely with minimal force when stopping. This greatly improves the accuracy of誘い using winding and stopping.

The Magnum Light rotor achieves significant weight reduction compared to rotors made of metal or high-strength resin. The 24 Vanford's Magnum Light rotor is about 34% lighter than the high-strength resin rotor of the 23 Stradic. It greatly contributes to improved response in lure operation and enhances the hand sensitivity of the angler, expanding the possibilities of new game styles.

Carbon fiber reinforced resin CI4+ that brings true lightweightness

True lightweight design in reels means achieving a new level of lightness without compromising strength or durability. Vanford aims to resolve this contradiction by adopting Shimano's proprietary carbon fiber reinforced resin CI4+ for the body and rotor. Despite being lightweight, CI4+ has excellent rigidity, suppressing deformation of the reel body and firmly guarding internal structures such as gear meshing. It maintains smooth rotation and drag performance over the long term.

Lightness, sensitivity, toughness. The core of the evolved MGL series

Infinity Cross

Reliable design and manufacturing technology result in overwhelming gear durability.

Design of gear teeth: Advances in drive gear and pinion gear contact surface area through manufacturing technology have improved. As a result, the load on gear teeth is more widely dispersed. This prevents concentrated damage and doubles the durability compared to conventional designs.

Infinity Drive

Powerful winding that always maintains the lead.

By supporting the main shaft, which was previously supported by a pinion gear, with a special low-friction bushing, sliding resistance is greatly reduced. Additionally, applying special surface treatment to the main shaft reduces rotational torque. This evolution allows the reel to actively wind even under high load.

Anti-twist fin

Line trouble suppression structure for more comfortable fishing.

An elastic fin is installed near the line roller to suppress line slack. This reduces phenomena such as line slipping off the spool bottom or being wound with twists.

Dura Cross

Outstanding wear resistance, smooth and reliable drag performance.

A new drag washer made with new materials: woven with fibers orthogonal to the conventional fiber direction to reinforce the material. It maintains smooth drag performance while more than tenfold increasing wear resistance.
