Panasonic Electric Works FY-STT10 System Components
FY-STT10
Part Number FY-STT10
Product Name Temperature Switch for Ventilation Fan, for 3-phase 200V Power Supply, Rated Current 10A or less
Applications Living Room, Office/Store, Warehouse/Factory, Other Features
● Automatically operates the ventilation fan when the ambient temperature exceeds the set temperature, and automatically stops when it falls below the set temperature by sensing the indoor temperature.
● 2-mode operation: Automatic - Continuous operation
● When using the temperature switch, please confirm that the rated current and starting current are compatible with the switch to be used.
● The sensing part inside the temperature switch can be removed and connected to control the ventilation fan by sensing the temperature away from the switch body. (Open the switch body, remove the sensing part, and connect with separately sold part (FY-STP01).)
● Please be sure to install the switch body vertically. Request
● Cannot be used with ventilation fans with pull-cord switches.
● For interlocked ventilation fans, please select models with electric or wind pressure type shutter structures.
● Never install in bathrooms.
● An auxiliary relay is required if the ventilation fan exceeds the control capacity.
| Product # | ED860275 |
|---|
