Code: 4582387108280

Brand: Audio Technica (Audio-Technica)

Standard: DC-3398 LL/0.2

Size information: 0.2m

About this product
A luxurious twisted 102 SSC DC cable with AWG18 size
Gold-plated plug molding
Twist structure that cancels noise
Includes marking stickers
› See more brands Audio Technica (Audio-Technica)
Features Compact
Gauge 18.0
Specifications conforming UL About this product
A luxurious twisted 102 SSC DC cable with AWG18 size
Gold-plated plug molding
Twist structure that cancels noise
Includes marking stickers
› See more

Shipping size: height 16.9, width 11, depth 1.1

Shipping weight: 20

A luxurious twisted 102 SSC DC cable with AWG18 size
Precision conductor 102 SSC, currently adopted in main products such as BLACKMAMBA-α V2 and Oyaide/NEO, characterized by clear expression from high to low frequencies.

This 102 SSC conductor, made with luxurious AWG18 size (0.75 sq) wire, compliant with UL standard AWM style 3398 rated at 300V and 150°C, with a permissible current of 10A, is used to create the 'DC-3398 LL', a DC power cable for effectors.

Since many effectors operate at 9-18V/100-250mA, the high specifications of 'DC-3398 LL' are obvious. The effect is expected to improve the sound clarity and resolution of your effectors, and to create a higher ceiling in the soundstage.

Additionally, the twist structure, a feature of 'DC-3398 LL', enables both noise resistance and good sound clarity.

Twist structure
For noise countermeasures, 'DC-3398 LL' balances the + and - lines by twisting them, canceling magnetic fields to ensure noise resistance suitable for live use. Also, the power line and ground line use the same cable, considering the return current flowing through the ground, to achieve clear sound quality and sound clarity. The simple twist structure, which directly expresses the characteristics of the 102 SSC wire without hindering current flow, is effective in effect change and harmonic amplification.

Gold-plated plug molding

Rare for DC plugs, it adopts a gold-plated plug. Designed for heavy-duty environments with frequent plugging and unplugging, finished with molding processing.

Marking stickers
When wiring inside a board, have you ever lost track of which DC cable connects the power supply and effectors? 'DC-3398 LL' includes marking stickers in three colors—red, silver, and blue—each with 2 sheets, totaling 6 sheets, for convenient cable replacement and review.



Conductor: 102 SSC AWG18
Standard: UL Standard AWM Style 3398
Plug size: 2.1mm
Insulator: XLPE
Rating: VW-1 / 150V, 300V (peak voltage 600V)
Included accessories: identification marking stickers (3 colors, 2 sheets each)
Manufacturer's description
Precision conductor 102 SSC

The precision conductor 102 SSC, currently adopted in main products such as BLACKMAMBA-α V2 and Oyaide/NEO, features high resolution, wide range, and flat expression.

This 102 SSC conductor, made with luxurious AWG18 size (0.75 sq) wire, compliant with UL standard AWM style 3398 rated at 300V and 150°C, with a permissible current of 6A, is used to create the 'DC-3398 LL', a DC power cable for effectors.

The high specifications of 'DC-3398 LL', capable of handling almost all effectors with a 300V 6A rating, are obvious. The effect is expected to improve the sound clarity and resolution of your effectors, and to create a higher ceiling in the soundstage.

Additionally, the twist structure, a feature of 'DC-3398 LL', enables both noise resistance and good sound clarity.

Twist structure

'DC-3398 LL' balances the + and - lines by twisting them, preventing electromagnetic induction noise by canceling magnetic fields, ensuring noise resistance suitable for live use. Also, the power line and ground line use the same cable, considering the return current flowing through the ground, to achieve clear sound quality and sound clarity. The simple twist structure, which directly expresses the characteristics of the 102 SSC wire without hindering current flow, is effective in effect change and harmonic amplification.

Gold-plated plug molding and marking stickers

It adopts a rare gold-plated plug for DC, improving conductivity and corrosion resistance. Designed for heavy-duty environments with frequent plugging and unplugging, finished with molding processing.

When wiring inside a board, have you ever lost track of which DC cable connects the power supply and effectors? 'DC-3398 LL' includes marking stickers in three colors—red, silver, and blue—each with 2 sheets, totaling 6 sheets, for convenient cable replacement and review.

Specifications
Conductor: 102 SSC AWG18
Insulator: XLPE
Standard: UL Standard AWM Style 3398
Rating: VW-1 / 150V, 300V (peak voltage 600V)
Plug size: 2.1mm
Included accessories: identification marking stickers in 3 colors, 2 sheets each
