Nippon Pisco
Manufacturer Inquiries: 0265-76-2511[Features]
● Excellent flexibility.
● Ideal for general pneumatic piping requiring a small bending radius.
● Cut marks are displayed at approximately 500mm intervals for convenient tube cutting.
[Specifications]
● Color: Black
● Outer diameter (mm): 3
● Inner diameter (mm): 2
● Minimum bending radius (mm): 8
● Fluid to be used: Air, Water (conditions apply)
● Total length (m): 20
[Specifications 2]
● Operating pressure: 0.8MPa (at 20°C, 65% RH)
● Operating vacuum pressure: -100kPa
● Operating temperature range: -15 to 60°C (provided freezing does not occur)
[Material/Finish]
● TPU (Thermoplastic Polyurethane)
[Notes]
● Do not apply stress such as tension, twisting, or extreme bending to the tube. This may cause the tube to collapse, burst, or detach.
● Do not scratch the tube by rubbing or tangling it. This may cause the tube to burst.
● The burst pressure of the tube decreases as the temperature rises, so understand the operating pressure and ensure a sufficient safety margin.
● Use the tube with a bending radius greater than or equal to the minimum bending radius.
● When piping the tube, allow for sufficient slack to account for changes in length, etc.
[Country of Origin]
Japan
| Product # | ED2280156 |
|---|
