Molex 5566-02A Crimp Terminal for Interconnection/PCB to Wire (10 pcs)

Molex 5566-02A Crimp Terminal for Interconnection/PCB to Wire (10 pcs)

  • $1.71 USD
Seller: edenki
Add to wishlist
Protection
ZenPlus Authenticity Guarantee, 30-days returns & 30 days money back guarantee. Details here.
Shipping
Your order will be shipped when ZenPlus receives all items from shops. Once shipped from Japan, estimated delivery time is 2-4 weeks for standard shipping and 3-4 days for express (DHL, UPS, FEDEX) shipping. ZenPlus covers shipping insurance to protect your items.
Payment
We ensure that your personal and payment information is kept secure by following PCI-DSS standards and using 256-bit encryption for all transactions.

[Product Description]
General Specifications
Product Family: Header for Circuit Boards
Series: 5566
Application: Power: Wire-to-Board
Comment: The maximum rated current when used with 45750 terminals (AWG16 AWG) is 13A. For details, please refer to the product specification sheet PS-45750-001.
Product Name: Mini-Fit Jr.™
Mechanical Performance / Material
Separable: No
Number of Poles (Maximum): 2
Color - Resin Part: Natural
Durability Insertion/Extraction Cycles: 30
Live Line Insertion/Extraction Compatible: No
Flexibility: 94V-2
Compatible with Grown Wires: No
Mating Guide: No
Mating Key: No
Mating Lock: Yes
Material - Metal Part: Brass
Plating - Mating Part: Tin
Plating - Terminal: Tin
Material - Resin Part: Nylon
Number of Rows: 2
Mounting Style: Straight
PCB Tail Length: 3.50mm (.138)
Positioning: Yes
PCB Retention: No
Recommended PCB Thickness: 1.60mm (.063)
Packaging: Poly Bag
Pitch - Mating Part: 4.20mm (.165)
Pitch - Mounting Part: 4.20mm (.165)
Plating Min - Mating: 0.889μm (35μ)
Plating Min - Termination: 2.540μm (100μ)
Mating Polarity: Yes
PCB Polarity: Yes
Shroud: Full Shield
Operating Temperature Range: -40°C to +105°C
Mounting Style: Through-Hole
Electrical Performance (Please refer to the product specification sheet for details.)
Maximum Rated Current: 13A
Maximum Rated Voltage: 600V
Agency Certification
CSA: LR19980
TUV: R72081037
UL: E29179
RoHS Compliant: Yes

Product # ED1187971
