Special:B0B92CSL1L
Code:4902901932465
Brand:Mitsubishi Electric (MITSUBISHI ELECTRIC)
Specification: V-143BZLT5
Product color: None
About this product
Quantity (units): 1 br V 143BZLT2 successor model br Equipped with 24-hour ventilation function br For 3 rooms ventilation br 100V power supply / for 3 rooms (1 room heating / 3 rooms ventilation) slim type / DC brushless motor br Connection pipe (mm): φ100 br Ceiling-mounted embedded dimensions (mm): 410 285 (when using ceiling-mounted auxiliary frame P 143TWT) br Wall embedded dimensions (mm): 410 285 br Body: Metal Brand Mitsubishi Electric (MITSUBISHI ELECTRIC)
Features: Swinging
Product dimensions: 49 cm depth x 60 cm width x 25 cm height
Color: None
Voltage: 100 volts About this product
Quantity (units): 1 br V 143BZLT2 successor model br Equipped with 24-hour ventilation function br For 3 rooms ventilation br 100V power supply / for 3 rooms (1 room heating / 3 rooms ventilation) slim type / DC brushless motor br Connection pipe (mm): φ100 br Ceiling-mounted embedded dimensions (mm): 410 285 (when using ceiling-mounted auxiliary frame P 143TWT) br Wall embedded dimensions (mm): 410 285 br Body: Metal
Shipping size: Height 53.8, Width 45.4, Depth 40.3
Shipping weight: 11050
Quantity (units): 1
V 143BZLT2 successor model
With 24-hour ventilation function
For 3 rooms ventilation
100V power supply / for 3 rooms (1 room heating / 3 rooms ventilation) slim type / DC brushless motor
Connection pipe (mm): φ100
Ceiling-mounted embedded dimensions (mm): 410 285 (when using ceiling-mounted auxiliary frame P 143TWT)
Wall embedded dimensions (mm): 410 285
Body: Metal
Fan (for ventilation circulation): Plastic
Grille: Plastic
Clothes drying, bathroom drying, heating, cool breeze, ventilation—5 functions in one unit
Simultaneous ventilation of bathroom, washroom, toilet, etc. (heating function only in bathroom)
Adopts a flat panel for easy cleaning
Equipped with PTC ceramic heater for heating and drying
Includes a
Cooling effect by circulation fan (summer)
Thermistor with over-temperature prevention and temperature fuse
External switch delay timer setting function for toilet (external)
Equipped with 24-hour ventilation function (4-stage airflow adjustment possible)
Ventilation airflow can be switched between strong (4 stages) and weak
Bathroom ventilation damper
Winter mode (24-hour ventilation airflow adjustment)
Low noise design
Maximum 12-hour
Pressure-shut shutter (exhaust)
Easy wiring: control switch connects with a connector one-touch (main unit power supply: 2-core, ground: 1-core, control switch: 3-core)
Quick-connect terminal connection
Optional intake port selectable from 3 directions
Incorrect wiring protection circuit
Accessories: 2 intake port grilles (with airflow adjustment plates), 2 intake ports, exhaust connection port, 1 intake port cover plate, mounting frame, control switch connection cord (effective length approx. 5m)
Dedicated control switch sold separately.
Cannot be used for single-room ventilation (bathroom only).
Standard compatible size is a bathroom of 1 tsubo (1600mm x 1600mm x 2200mm). The larger the bathroom, the longer the drying time and the reduced heating effect.
Cannot be installed on inclined ceilings.
Drying and heating effects vary depending on outside air temperature and bathroom structure (walls, floor materials, size).
Please contact the relevant supervising authority (such as the fire department) for details regarding restrictions on installation in your area.
This product is for residential use. Cannot be used for commercial purposes.
Do not use in hot springs, pools, etc.
Please use the dedicated control switch (sold separately) for this model. Using other control switches may prevent proper operation.
It may take up to 40 seconds to start operation or switch functions. This is not a malfunction, as it involves airflow switching or cooling of the main unit.
After power-on, if ventilation is started, a few minutes of fan adjustment operation will be performed.
There is no ventilation linkage output function.
Replacement from Mitsubishi Electric existing products (such as V 143BZL5) is not possible due to different embedded dimensions.
This product is for wall-mounted installation only.
| Product # |
202507291828244902901932465 |
