Special:B083R7MM59
Code:0889523034231
Brand:GIGABYTE
Model: B650M DS3H
Product size: Height 6.8, Width 26.8, Depth 27
Product weight: 1428.8
About this product
MB5900 Japan authorized dealer product, 2-year warranty
This motherboard supports AMD Ryzen 7000 series CPUs.
6+2+1 power phases (DrMOS) allow for stable operation even under high load for extended periods.
Equipped with two M.2 ports supporting PCIe 4.0 4 connections, delivering excellent performance.
Equipped with Realtek 2.5G LAN, enabling high-speed wired network connection.
› See more Brand GIGABYTE
CPU socket Socket AM5
Supported device: PC
RAM memory technology DDR5
Supported processor: AMD Ryzen 7000 series About this product
MB5900 Japan authorized dealer product, 2-year warranty
This motherboard supports AMD Ryzen 7000 series CPUs.
6+2+1 power phases (DrMOS) allow for stable operation even under high load for extended periods.
Equipped with two M.2 ports supporting PCIe 4.0 4 connections, delivering excellent performance.
Equipped with Realtek 2.5G LAN, enabling high-speed wired network connection.
› See more
Shipping size: Height 27.4, Width 27, Depth 7.3
Shipping weight: 1501
Micro-ATX size motherboard with AMD B650 chipset and Q-Flash Plus function.
Number of power phases: 6 (DrMOS) +2+1
Main PCIe slot: 1*PCIe 4.0 x16
Graphics ports: HDMI, 2*DP
Supported memory: Dual-Channel DDR5
Memory slots: 4*DIMMs
Expansion slots: 1*PCIe 3.0 x1
SATA / M.2: 4*SATA3, 2*M.2 Gen 4
SATA RAID: RAID 0, 1, 10
Audio: ALC897
Wired LAN: Realtek 2.5GbE LAN
USB (rear): USB 3.2 Gen 2 Type-C, 1*USB 3.2 Gen 2 Type-A, 2*USB 3.2 Gen 1, 4*USB 2.0
USB (front): USB 3.2 Gen 2 Type-C, USB 3.2 Gen 2, 2*USB 3.2 Gen 1, 4*USB 2.0
Wireless LAN: -
Form factor: mATX (244x244) Brand introduction
Motherboard
Access store
Graphics card
Access store
Display
Access store
PC accessories
Access store
Laptop
Manufacturer's description
Product features
AMD AM5 socket: Supports AMD Ryzen 7000 series processors
Overwhelming performance: Direct drive 6+2+1 power phase design
Dual Channel DDR5: 4 memory slots (AMD EXPO & Intel XMP compatible)
High-performance storage: Equipped with 2*PCIe 4.0 x4 M.2 connectors
Large heatsink & M.2 Thermal Guard: Excellent heat dissipation for power phases & M.2 SSDs
EZ-Latch: Click-release design for PCIe x16 slot
High-speed network: 2.5 GbE wired LAN
Rich connectivity: 2*DP, HDMI, front & rear USB-C 10Gb/s compatible
Equipped with Smart Fan 6
Equipped with Q-Flash Plus
Product features
6+2+1 digital power phase design
Provides cleaner and more efficient power, ensuring stability at high CPU frequencies and loads.
Digital PWM controller for appropriate voltage supply to CPU.
Direct drive 6+2+1 power phase design.
Uses solid capacitors to improve transient response and suppress voltage ripple.
8 solid pin CPU power connector.
High-efficiency heat dissipation design
Large heatsink
The large heatsink significantly improves heat dissipation.
High-efficiency structure
Structure that improves airflow and increases total contact surface.
6-layer 2X copper thin-layer PCB
2X copper thin-layer PCB effectively lowers component temperatures due to high thermal conductivity and low impedance.
PCIe 4.0 compatible M.2 connector
The B650M DS3H features two PCIe 4.0 M.2 slots.
M.2 Thermal Guard releases heat before issues occur, preventing throttling and bottlenecks of high-speed M.2 SSDs.
USB 3.2 Gen 2 Type-C
Adopts USB 3.2 Gen 2 design with twice the performance of previous USB 3.2 Gen 1, enabling theoretical 10Gbps high-speed data transfer with USB 3.2 compliant peripherals.
Also features a reversible USB Type-C connector for quick connection and fast access and storage of large data.
2.5 GbE wired LAN
Realtek Ethernet controller supports 2.5GBASE-T / 1000BASE-T / 100BASE-TX, providing a theoretical 2.5 GbE network connection, approximately 2.5 times faster than standard 1GbE networking, designed for workstations and gamers.
High-quality audio
High-quality audio capacitors
GIGABYTE motherboards use high-end audio capacitors. These high-quality capacitors provide high-resolution and high-fidelity audio, helping deliver the most realistic sound effects for gamers.
Audio Noise Guard
GIGABYTE motherboards feature an audio noise guard that isolates sensitive analog audio components from potential noise contamination at the PCB level.
Product specifications
| Product # |
202505110310410889523034231 |
